HOT CAMS CAM TRX400EX STAGE 2 1043-2
CAMHAFTS SINGLE STAGE 2
€401.25
Άμεσα διαθέσιμο — 2 τεμάχια
Άμεσα διαθέσιμο — 2 τεμάχια
Description
Camshaft Stage 2
Slight mid range gain and top end power increase.
Does not use an auto-decompression mechanism.
Stock starter is sufficient.
For single cam engine.
Uses stock valve springs and rockers.
Intake Valve Lash: 0.130 mm.
Exhaust Valve Lash: 0.150 mm.
- Computer Numerical Control (CNC) from 8620 billet steel and case harden
- Designed and dyno proven in the USA
- Engineered by using valvetrain software
- Adds a 5%-10% power gain
- Select cams feature Hot Cams Improved Throttle Design (I.T.R.) technology; these cams improve throttle response throughout the entire rpm range while providing excellent power gains through the mid-range and top-end
- Designed for mid to top end gains.
- Engineered to be drop in cams that use stock valve springs (unless otherwise noted).
Specification
Overview
| Βάρος | .588 γρ. |
|---|---|
| Διαστάσεις | 250.000 × 80.000 × 78.000 mm |
| Exhaust Duration Imperial | 248.500° |
| Units | Each |
| Intake Lobe Centerline | 106° |
| Intake Duration Imperial | 254° |
| Type | Stage 2 |
| Intake Duration | 254° |
| Intake Lift Metric | 9.00 mm |
| Product Name | Camshaft |
| Exhaust Duration | 248,500° |
| Exhaust Lift | 8,90 mm |
| Exhaust Lobe Centerline | 104,250° |
| Application | Exhaust, Intake |
| Exhaust Lobe Centerline Imperial | 104.250° |
| Intake Lobe Centerline Imperial | 106° |
| Riding Style | ATV, Off-Road |
| Exhaust Lift Metric | 8.90 mm |
| Intake Lift | 9,00 mm |
